Calcium Fluoride Infrared Optics For A Range Of Laser IR And UV Applications

Calcium Fluoride Infrared Optics For A Range Of Laser IR And UV Applications

Product Details:

Place of Origin: China
Brand Name: BonTek
Certification: ISO:9001
Model Number: Calcium Fluoride (CaF2)

Payment & Shipping Terms:

Minimum Order Quantity: 5 Pieces
Price: Negotiable
Packaging Details: Cassette / Jar, put in a carton with PE foam.
Delivery Time: 1-4 weeks
Payment Terms: T/T
Supply Ability: 10000 pieces/Month
Get Best Price Contact Now

Detail Information

Category: Infrared Optics Material: Calcium Fluoride (CaF2)
Crystal Orientation: <111>, <100> Or Random Density: 3.18 Gm/cc
Diameter: 5mm - 300mm Thickness: 1mm - 50mm
Transmission Range: 0.15um - 7.00um Refractive Index Homogeneity: Range 3 To 15ppm @632.8nm PV
High Light:

CaF2 Infrared Optics

,

Calcium Fluoride Crystal

,

1mm Infrared Optics

Product Description

High-Purity Calcium Fluoride Infrared Optics for a Range of Laser, IR And UV Applications



The wide transmission range, refractive index homogeneity and high laser-damage threshold make CaF2 ideal for eximer laser products. Optical components for UV, through visible and infrared benefit from high durability to normal atmospheres and CaF2's low solubility and its resistance to reagents. Laser components, from lenses and windows, to beam-steering prisms and mirrors are offered in high-purity Calcium Fluoride material.



BonTek provides optical CaF2 material in single-crystal optical quality, fabricated to order.



Substance

Form

Diameter Range

Thickness Range

Transmission Range

Standard Surface Finish

Calcium Fluoride Single Crystal 5mm - 300mm 1mm - 50mm 0.15 - 7.00 um Fine Ground / Optical Polish





Material Properties

Transmission Range

0.15 - 7.0 microns

Internal Transmission

>99.5% from 193nm to 7µm

Refractive Index Homogeneity

Range 3 to 15ppm @632.8nm PV

Bubbles & Inclusions

1/1 x 0.050 (typ.)

Stress Birefringence

Range 0.5nm/cm to 15nm/cm @632.8nm

Crystal Orientation

<111>, <100> or Random

Density

3.18 gm/cc

Melting Point

1420°C

Poisson Ratio (µ)

0.260

Knopp Hardness

158.3 Knoop

Crystal Structure

Cubic

Young's Modulus [GPa]

75.8

Shear Modulus [GPa]

33.77



Calcium Fluoride Infrared Optics For A Range Of Laser IR And UV Applications 0Calcium Fluoride Infrared Optics For A Range Of Laser IR And UV Applications 1Calcium Fluoride Infrared Optics For A Range Of Laser IR And UV Applications 2



Calcium Fluoride Infrared Optics For A Range Of Laser IR And UV Applications 3



Calcium Fluoride Infrared Optics For A Range Of Laser IR And UV Applications 4





Acceptance Check

Calcium Fluoride Infrared Optics For A Range Of Laser IR And UV Applications 5



1. The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.



2. After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.



3. Please open the vacuum package in a clean room when the products are to be applied.



4. If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
