LiNbO3 LiTaO3 Quartz Piezo Wafer For Piezoelectric Sensor and Transducer
Product Details:
| Place of Origin: | China |
| Brand Name: | BonTek |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Piezoelectric Wafer |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette/ Jar package, vaccum sealed |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 50000 pcs/Month |
|
Detail Information |
|||
| Product Name: | Piezoelectric Wafer | Diameter: | 3 Inch, 4 Inch, 5 Inch |
|---|---|---|---|
| Crystal: | Lithium Tantalate, Crystal Quartz, Lithium Niobate | Thickness: | 0.35mm, 0.5mm, 0.675mm |
| Orientation Flat: | 22mm, 32.5mm, 57.5mm | Finish: | Polish, Lap, Etch |
| Applications: | Piezoelectric Devices | Ra Roughness: | <5A, <10A |
| High Light: | Piezoelectric Sensor Piezo Wafer,LiTaO3 Quartz Wafer,Transducer Piezo Wafer |
||
Product Description
LiNbO3 LiTaO3 Quartz Piezoelectric Wafer For Piezoelectric Sensor and Transducer
With the Piezoelectric Effect the most unique trait of this effect is that it works two ways. You can apply mechanical energy or electrical energy to the same piezoelectric material and get an opposite result.
BonTek grows crystal and fabricate wafers, we are piezoelectric specialist. We work mostly with wafers, blanks, substrates made from Quartz Crystal, Lithium Niobate, Lithium Tantalate etc.
|
Crystal |
Quartz Crystal | Lithium Niobate | Lithium Tantalate |
|
Orientation |
X / Y / Z / Y36 / Y42.75 |
X / Y / Y41 / Y64 / Y128 |
X / X112 / YZ / Y28 / Y36 / Y42 |
|
Curie Temp |
573℃ | 1142℃ ± 2℃ | 605℃ ± 2℃ |
|
Color |
White Clear | White Standard, Black Reduced | |
|
Doped with |
with or without seed | Er, MgO | Fe |
|
Diameter |
3’’, 4’’, 5’’, 6’’, 8’’ | 3’’, 4’’, 6’’ | |
|
Thickness |
0.08mm / 0.25mm / 0.35mm / 0.50mm / 1.00mm / 2.00mm |
0.35mm / 0.50mm / 1.00mm / 2.00mm | |
|
Surface finish |
Single side polish / Double side polish (SSP/DSP) | ||
|
Front Side |
Roughness Ra<=10A | Roughness Ra<=5A | |
|
Back/ Criteria |
Roughness Ra: 0.5--1.0um GC#1000 | ||
|
TTV |
< 5um |
||
|
Bow |
-25um < bow < ＋25um | ||
|
Warp |
< 35um | ||
|
LTV (5x5) |
< 1.5um | ||
|
PLTV |
>98% (5mm*5mm) | ||
|
Edge |
CompI’ t with SEMI M1.2 @ with GC#1000 | ||
|
Orientation Flats |
22±2mm, 32.5±2mm, 47.5±2mm, 57.5±2mm, Notch As per request | ||
|
Contamination |
Particles @ >0.3 micron | ||
|
Appearance |
Cracks, saw marks, stains: None | ||
