Y Cut Single Crystal Quartz Wafer Ring Double Side Lapped For Sensing Technology

Y Cut Single Crystal Quartz Wafer Ring Double Side Lapped For Sensing Technology

Product Details:

Place of Origin: China
Brand Name: BonTek
Certification: ISO:14001
Model Number: Single Crystal Quartz

Payment & Shipping Terms:

Minimum Order Quantity: 50 pcs
Price: Negotiable
Packaging Details: Film package, vaccum sealed
Delivery Time: 1-4 weeks
Payment Terms: T/T
Supply Ability: 50000 pcs / Month
Get Best Price Contact Now

Detail Information

Material: Crystal Quartz Ring Shape: Ring, Wafer With Hole
Cut Type: X-cut, Y-cut, Etc. Surface: Lapped, Double Side Polish
Inner Dia.: 1.5mm Up Q-value: 1.8M, 2.0M, 2.4M
Inclusion: I, II, III Grade ECD: 10cm2, 30cm2, 100cm2
High Light:

Y Cut Single Crystal Sapphire Wafer

,

Single Crystal Wafer With Hole

,

Double Side Lapped Quartz Wafer

Product Description

X-cut Y-cut Crystal Quartz Ring Double Side Lapped for Sensing Technology



Piezo Quartz exhibits the best long term stability of any piezoelectric sensing material. Quartz exhibits no pyro-electric output and has a small stable thermal coefficient. The low capacitance of quartz gives it a high voltage output (V=Q/C).



BonTek Optoelectronics has enormous experience in Crystal Quartz Ring fabrication. We make 10 thounds of quartz rings and LiNbO3 rings each year. They are mostly used as the key element in pressure or force sensors. We can customize the outter dia., inner dia., surface finish, and cut angle for you.



Y Cut Single Crystal Quartz Wafer Ring Double Side Lapped For Sensing Technology 0Y Cut Single Crystal Quartz Wafer Ring Double Side Lapped For Sensing Technology 1Y Cut Single Crystal Quartz Wafer Ring Double Side Lapped For Sensing Technology 2



Material

Single Crystal Quartz Blanks (Piezo / Optical grade)

Synthetic Q-Value

Min 1.8×10^6, 2.4×10^6, 3.0×10^6 (IEC standards)

Etch Channel Density (ECD)

2/cm2,10/ cm2,30/ cm2,100/ cm2,300/cm2;Swept Quartz (IEC standards)

Inclusions Density

Ia,Ib,I, II,III Grades (IEC standards)

Cutting Angle

X / Y / Z / AT / BT / ST etc.

Outter Diameter

3mm ~ 200mm

Inner Diameter

1.5mm ~ 100mm

Thickness

0.1mm ~ 5mm

Orientation Flat

As required, or Pencil marked

Surface Finish

Double side lapped, Double side polished

Polished side Ra

<1nm or specific per requested

Back Side Criteria

General is 0.2-0.5µm or as customized



Y Cut Single Crystal Quartz Wafer Ring Double Side Lapped For Sensing Technology 3



Y Cut Single Crystal Quartz Wafer Ring Double Side Lapped For Sensing Technology 4





Acceptance Check

Y Cut Single Crystal Quartz Wafer Ring Double Side Lapped For Sensing Technology 5



  • The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.



  • After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.

  • Please open the vacuum package in a clean room when the products are to be applied.



  • If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
