2'' 3'' Ultra-Thin Piezoelectric Wafer 50um Quartz Film And LT Film For Piezo Devices
Product Details:
| Place of Origin: | China |
| Brand Name: | BonTek |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Piezoelectric Wafer |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette/ Jar package, vaccum sealed |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 50000 pcs/Month |
|
Detail Information |
|||
| Product: | Piezoelectric Wafer | Diameter: | 2'', 3'', 4'' |
|---|---|---|---|
| Crystal: | LiTaO3, LiNbO3, Quartz Crystal | Thickness: | 50um, 70um, 90um, 100um, 200um |
| Primary Flat: | 22mm, 32.5mm | Surface Finish: | Double Side Polish, Single Side Polish |
| Application: | Piezo Devices, Pyroelectric Devices | Inspection Report: | TTV, BOW, Warp, Ra |
| High Light: | 3'' Piezoelectric Wafer,lithium niobate wafer 50um,2'' Piezoelectric Wafer |
||
Product Description
2'' 3'' Ultra-thin Piezoelectric Wafer 50um Quartz Film and LT Film for Piezo Devices
The piezoelectric effect in a crystal is explained as that there will be the development of electric charges on the metal surfaces when certain pressure or stress is applied to the piezoelectric crystal. Piezoelectric constant is piezoelectric medium convert mechanical energy (or energy) to electricity (or mechanical energy) of proportionality constant, (T) reflects the stress and strain (S), the electric field (E), or the connection between the electric displacement (D), directly reflects the mechanical and electrical properties of the coupling relationship and the strength of the piezoelectric effect.
BonTek grows crystal and fabricate wafers, we are piezoelectric specialist. We work mostly with wafers, blanks, substrates made from Quartz Crystal, Lithium Niobate, Lithium Tantalate, Fluoride, Glass etc.
| Crystal | Quartz Crystal | Lithium Niobate | Lithium Tantalate |
| Orientation | X / Y / Z / Y36 / Y42.75 |
X / Y / Y41 / Y64 / Y128 |
X / X112 / YZ / Y28 / Y36 / Y42 |
| Curie Temp | 573℃ | 1142℃ ± 2℃ | 605℃ ± 2℃ |
| Colour | White Clear | White Standard, Black Reduced | |
| Doping | with seed or seedless | Er & MgO | Fe |
| Out Diameter | 3’’, 4’’, 5’’, 6’’, 8’’ | 3’’, 4’’, 6’’ | |
| Thickness | 0.08mm / 0.25mm / 0.35mm / 0.50mm / 1.00mm etc. |
0.35mm / 0.50mm / 1.00mm / 2.00mm etc. |
|
| Surface Finish | Single side polish / Double side polish / Lapped | ||
| Front Side | Ra<=10A | Roughness Ra<=5A | |
| Backside | Roughness Ra: 0.5--1.0um GC#1000 | ||
| TTV | < 5um | ||
| Bow | -25um < bow < ＋25um | ||
| Warp | < 35um | ||
| LTV (5x5) | < 1.5um | ||
| PLTV | >98% (5mm*5mm) | ||
| Edge | CompI’ t with SEMI M1.2 @ with GC#1000 | ||
| Orientation Flats | 22±2mm, 32.5±2mm, 47.5±2mm, 57.5±2mm, Notch As per request | ||
| Contamination | Particles @ >0.3 micron | ||
| Appearance | Cracks, saw marks, stains: None | ||
