10mm Square Fe Doped SrTiO3 Crystal Wafer For Semiconductor



Fe-doped strontium titanate (SrTiO3) and strontium titanate single crystal have similar structure. Strontium titanate single crystal is well matched with a variety of perovskite mineral structure materials, which is a high quality substrate material for high-temperature superconducting thin films and a variety of oxide thin films, and also widely used in special optical Windows and high quality sputtering targets. At present, BonTek can provide Fe:SrTiO3 single crystal substrate with iron doped concentration of 0.04% and 0.05%.



Square Fe Doped SrTiO3 Crystal Wafer For Semiconductor 10mm 0Square Fe Doped SrTiO3 Crystal Wafer For Semiconductor 10mm 1Square Fe Doped SrTiO3 Crystal Wafer For Semiconductor 10mm 2





SrTiO3 Crystal
Crystal structure Cubic system (a=3.905Å)
Density 5.122 g/cm3
Dopant Intrinsic, Fe doped, neodymium (Nd) doped, Niobium doped
Hardness 6~6.5 (Mohs)
Coefficient of thermal expansion 10.4×10-6/k
Dielectric constant 5.2
Orientation <100>,<110>,<111>±0.5o,as required
Dimension 10×3mm, 10×5mm, 10×10mm, 15×15mm, 20×15mm
Thickness 0.5±0.015mm, 1±0.015mm
Surface Finish Single side polish, Double side polish
Surface Roughness ≤5Å
Package 100 Class Clean Bag, Jar package, Film package
