Revolutionize Your Instrumentation Systems with Single Crystal Quartz Wafers for SAW and MEMS Device Production
Product Details:
| Place of Origin: | China |
| Brand Name: | CQT |
| Certification: | ISO:9001 |
| Model Number: | Single Crystal Quartz |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette / Jar, put in a carton with PE foam. |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 100000 pcs / Month |
|
Detail Information |
|||
| Product: | Single Crystal Quartz | Diameter: | 3" 4" 6" |
|---|---|---|---|
| Cut Angle: | AT-cut, ST-cut, Z-cut, X-cut | Thickness: | 0.20mm 0.35mm, 0.5mm,1.0mm |
| Surface: | DSP SSP | Growth: | Hydrothermal Growth |
| Inclusion: | Ia, Ib, I, II, III | Application: | MEMS, SAW Application |
| Highlight: | Single Crystal Quartz Wafers,SAW Single Crystal Quartz Wafers,MEMS Single Crystal Quartz Wafers |
||
Product Description
Revolutionize Your Instrumentation Systems with Single Crystal Quartz Wafers for SAW and MEMS Device Production
Unleash Unmatched Precision with Single Crystal Quartz!
In the realm of precision technology, every micron counts. Enter our Single Crystal Quartz – the epitome of accuracy and reliability. Engineered with unparalleled craftsmanship, this material offers unparalleled stability, making it the gold standard for frequency control applications.
Single Crystal Quartz is the cornerstone of high-end timekeeping devices, oscillators, and sensors. Its exceptional piezoelectric properties ensure consistent and accurate signal transmission, even under the most extreme conditions. Whether you're developing cutting-edge communication systems, advanced medical equipment, or precision navigation tools, our Single Crystal Quartz delivers unwavering performance.
Don't compromise on quality. Choose Single Crystal Quartz for your next project and experience the difference that precision makes. Elevate your technology to new heights with the material that sets the standard for excellence. Order now and embrace the future of precision!
| Single Crystal Quartz Material Properties | |
| Purity | Optical grade: 99.99% |
| Crystal Structure and lattice parameters |
Hexagonal a= 4.914 Å c = 5.405 Å |
| Growth Method | Hydrothermal method |
| Hardness | 7.0 Mohs |
| Density | 2.684 g/cm3 |
| Melt Point | 1610 deg C (phase transition point: 573.1 °C) |
| Specific heat | 0.18 cal/g |
| Thermoelectric Constant | 1200 mV / °C @ 300 °C |
| Thermal conductivity | 0.0033 cal/cm/ °C |
| Thermal expansion coefficient, (CTE) (x10^-6/ K) |
perpendicular to Z axis: 13.71 parallel to Z axis: 7.48 |
| Refractive Index | 1.544 |
|
Q value Acoustic velocity, SAW Frequency constant, BAW Piezoelectric coupling, |
1.8 x 10^6; 2.4 x 10^6, 3.0 x 10^6 3160 ( m/sec ) 1661 ( kHz/mm ) K2 (%) BAW: 0.65 SAW: 0.14 |
| Inclusion | IEC Grade II |
| Diameter | 3”(76.2mm) | 4”(100mm) | 6”(150mm) | 8”(200mm) |
| Thickness | 0.08mm Min-up | 0.10mm Min-up | 0.20mm Min -up | 0.35mm Min- |
| Primary Flat | 22mm | 32mm | 42.5mm | 57.5mm or notch |
| Surface | LTV (5mmx5mm) | <1.5µm | TTV | <1.5~3 µm |
| Bow | -30<bow<30 | Warp | <40µm | |
| Surface Type | SSP / DSP | Edge Criteria | R=0.2mm or Bullnose | |
| Polished side Ra | <0.5nm or per requested | Back Side Criteria | 0.2-0.5µm or as customized |
