Product Details:

Place of Origin: China
Brand Name: CSIMC
Certification: ISO:9001, ISO:14001
Model Number: MgO wafer

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Cassette/ Jar package, vaccum sealed
Delivery Time: 1-4 weeks
Payment Terms: T/T
Supply Ability: 10000 pcs/Month
Get Best Price Contact Now

Detail Information

Materials: MgO Wafer Size: 10x10,15x15,20x15,20x20mm
Thickness: 0.5mm,1.0mm Surface Finish: DSP SSP
Hardness: 5.5(mohs) Density (g/cm3): 3.58

Product Description

Unleash the Full Potential of Your Optoelectronic Devices with Our High Thermal Conductivity MgO Single Crystal Substrate



Introducing our premium MgO (Magnesium Oxide) Single Crystal Substrates, the cornerstone for cutting-edge research and high-performance device fabrication.

Our MgO single crystal substrates boast exceptional purity and crystal quality, ensuring minimal defects and uniform properties across the surface. This makes them ideal for applications in epitaxial growth of thin films, such as superconductors, ferroelectrics, and magnetic materials.

With precise dimensional control and excellent surface finish, our substrates provide a stable and reliable platform for your experiments and production processes. Whether you're working in academia or industry, our MgO single crystal substrates offer the consistency and performance you need to achieve outstanding results. Choose our substrates and take your research and development to the next level. Contact us today to discuss your specific requirements and experience the difference our high-quality products can make.



Unleash the Full Potential of Your Optoelectronic Devices with Our High Thermal Conductivity MgO Single Crystal Substrate 0

Main performance parameters
Growth method arc melting method
Crystal structure cube
Lattice constant a=4.130 Å
Melting point (℃) 2800
purity 99.95%
Density (g/cm3) 3.58
hardness 5.5(mohs)
Coefficient of thermal expansion (/℃) 11.2x10-6
Crystal cleavage plane <100>
Optical transmission >90%(200~400nm),>98%(500~1000nm)
Dielectric constant ε= 9.65
Thermal conductivity (CAL/KCM/s) 0.14 300°K
Ra: ≤5Å(5µm×5µm)
Packing 100 clean bags, 1000 super clean room







Unleash the Full Potential of Your Optoelectronic Devices with Our High Thermal Conductivity MgO Single Crystal Substrate 1



Unleash the Full Potential of Your Optoelectronic Devices with Our High Thermal Conductivity MgO Single Crystal Substrate 2





FAQs:



  1. Q: What are the products you mainly work on?

A: We look at ourselves as the piezo wafer specialist. We are the very first to work with Single Crystal Quartz in China about 30 years ago. Then gradually we step in the field of LiNbO3, LiTaO3, Quartz glass, LGS, CTGS etc. Especially, if you are looking for a piezo quartz supplier, we are the ultimate choice! We export millions of quartz blanks each year because we master the AT, SC and IT cuts with superior angle precision.



  1. Q: Can you accept product customization?

A: Yes, of course. We can fabricate as per your request. In addition, we are so experienced with piezo wafers that we can provide you relevant suggestions if you are not 100% sure about your choice. Besides, we do have some standard wafers in stock, please check with us.



  1. Q: Can you deliver the goods via our courier agent?

A: Yes, we would suggest you go with the courier agent you are most familiar with (DHL, FedEX, UPS etc.). We can ship via your account. And, of course, we will pack the products safely in acceptable size to help you save the shipping cost. If you need us to take care of the freight, it’s also not a problem. We also have good discount with the international courier companies.



  1. Q: How can you guarantee we get what we want safely?

A: The wafer products are fragile and sometimes expensive. The last thing, as the manufacturer, we want to see is the products we make were damaged during courier. As a result, we will pack the wafers adequately and put them in a proper carton filled with buffer sponge. However, accidents are inevitable sometimes. So, please follow the “Acceptance check” steps shown in the drawings below. If the unwanted happened, we will either give the replenishment or refund if you follow the checking steps.





Acceptance Check

Unleash the Full Potential of Your Optoelectronic Devices with Our High Thermal Conductivity MgO Single Crystal Substrate 3



  • The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.



  • After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.

  • Please open the vacuum package in a clean room when the products are to be applied.



  • If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.

Want to Know more details about this product
I am interested in Unleash the Full Potential of Your Optoelectronic Devices with Our High Thermal Conductivity MgO Single Crystal Substrate could you send me more details such as type, size, quantity, material, etc.
Thanks!
Waiting for your reply.
