5mol% MgO Doped LiNbO3 Wafers Optimal Material for High-Performance Optoelectronics
Product Details:
| Place of Origin: | China |
| Brand Name: | CQT |
| Certification: | ISO:9001, ISO:14001 |
| Model Number: | Lithium Niobate (LiNbO3) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cassette/ Jar package, vaccum sealed |
| Delivery Time: | 1-4 weeks |
| Payment Terms: | T/T |
| Supply Ability: | 20000 pcs/Month |
|
Detail Information |
|||
| Material: | LiNbO3 Wafer | Out Diameter: | 3'', 4'' |
|---|---|---|---|
| Orientation: | X, Z, Etc. | Doping: | 5% MgO:LN |
| Thickness: | 0.25mm - 3mm | Surface Finish: | DSP |
| Grade: | Optical Grade | Application: | SAW Filter, Ultrasonic Transducer |
Product Description
5mol% MgO Doped LiNbO3 Wafers Optimal Material for High-Performance Optoelectronics
Unlock unparalleled optical and nonlinear performance with our premium 5mol% MgO-doped Lithium Niobate (LiNbO₃) wafers—engineered to meet the most demanding requirements of modern photonics and telecommunications. By incorporating 5mol% MgO, these wafers exhibit significantly enhanced resistance to photorefractive damage, improved thermal stability, and higher optical damage thresholds compared to undoped counterparts, making them ideal for high-power laser systems and nonlinear frequency conversion.
Crafted with ultra-low defect density and precise thickness control, our wafers ensure consistent, high-quality performance in applications such as electro-optic modulators, acousto-optic devices, and integrated photonic circuits. The congruent composition and oriented crystal structure guarantee excellent piezoelectric and electro-optic coefficients, enabling superior signal processing and sensing capabilities.
Available in customizable diameters and polished finishes, our 5mol% MgO:LiNbO₃ wafers are the trusted choice for leading research institutions and industry innovators. Elevate your projects with our cutting-edge material—contact us today to request a quote and experience the difference in precision and reliability.
|
Material |
3" 4" 6" 8" LN wafer (Saw/Optical grade) |
|
Orientation Cut |
Y64°, Y128°, YZ or Customized |
|
Surface finish |
single or double sides polish (DLP/SLP/ SSP/DSP all available ) |
|
Thickness |
0.18/0.25/0.35/0.50/1.00 + mm |
|
TTV |
< 1~5µm |
|
BOW |
± (25µm ~40um ) |
|
Warp |
<= 35µm |
|
LTV (5mmx5mm) |
<1.5 um |
|
PLTV(<0.5um) |
≥98% (5mm*5mm) with 2mm edge excluded |
|
Curie Temp |
1142°C±3°C |
|
Edge Rouding |
Compl't with SEMI M1.2@with GC800# .regular at C typed |
|
Orientation flats |
available, per request |
|
Polished side Ra |
Roughness Ra<=5A |
|
Back Side Criteria |
Roughness Ra:0.5-1.0µm GC#1000 |
|
Cracks, saw marks, stains |
None |
|
Single Domain |
Completed Polarization/Reduced |
FAQs:
- Q: Can you accept product customization?
A: Yes, of course. We can fabricate as per your request. In addition, we are so experienced with piezo wafers that we can provide you relevant suggestions if you are not 100% sure about your choice. Besides, we do have some standard wafers in stock, please check with us.
- Q: Can you deliver the goods via our courier agent?
A: Yes, we would suggest you go with the courier agent you are most familiar with (DHL, FedEX, UPS etc.). We can ship via your account. And, of course, we will pack the products safely in acceptable size to help you save the shipping cost. If you need us to take care of the freight, it’s also not a problem. We also have good discount with the international courier companies.
Acceptance Check
- The product is fragile. We have adequately packed it and labeled it fragile. We deliver through excellent domestic and international express companies to ensure transportation quality.
- After receiving the goods, please handle with care and check whether the outer carton is in good condition. Carefully open the outer carton and check whether the packing boxes are in alignment. Take a picture before you take them out.
- Please open the vacuum package in a clean room when the products are to be applied.
- If the products are found damaged during courier, please take a picture or record a video immediately. DO NOT take the damaged products out of the packaging box! Contact us immediately and we will solve the problem well.
